Hello, Difficult to say without the code. I guess you may be accessing the list of tools with an out of range index. To prevent that, you can add an if condition before accessing it. Ie: var toolIndex: Integer; begin toolIndex:=myIndex; if toolIndex >= Chart1.Tools.Count then Exit; // Now it should ...

Hello, Oups that was a spoiler of a new functionality for the next release. Currently, to draw transparent shapes you need manually call BeginBlending and EndBlending . Ie: uses Chart, Series, TeeTools, TeCanvas; //... procedure TForm1.BeforeDrawAxes(Sender: TObject); var rect: TRect; blend: TTeeBle...

Hello, Assuming you know you have those ColorLine tools, you can use them to calculate the rectangle and draw it at OnBeforeDrawAxes event. Ie: quadrant.png uses Chart, Series, TeeTools; var Chart1: TChart; HorizLine, VertLine: TColorLineTool; procedure TForm1.FormCreate(Sender: TObject); begin Char...

Hello, At the TStringGrid demo, the OnSelect event is used as follows to get the row and other info from the clicked/tapped cell: // Called when selecting a cell, by mouse click, touch, or arrow keys procedure TStringGridForm.TeeGrid1Select(Sender: TObject); var tmp : TGridSelection; begin tmp:=TeeG...

Hello Thomas,

Try setting AnnotationValue to False.

Hello,

Take a look at this guide.

Hello, This looks more a matter of calculating the width of the axis label than the gantt series. I'd suggest you to take a look a the PlaceAxis method I implemented time ago ( here ). It should allow you to set the margin your axis labels require. If you still find problems with it, please don't he...

Hello,

Yes, we'll publish new installers as soon as possible.

Hello Ana, Looking at the log, it's highly possible that's a side effect of a bug in v2025.44 ( #2777 ), which was identified and fixed here . Find below the full git diff: --- a/Chart.pas +++ b/Chart.pas @@ -418,6 +418,7 @@ type ILegend : TCustomChartLegend; + procedure FontChanged(Sender: TObject)...

Hello, Yes, that's a side effect of a bug in v2025.44 ( #2777 ), which was identified and fixed here . Find below the full git diff: --- a/Chart.pas +++ b/Chart.pas @@ -418,6 +418,7 @@ type ILegend : TCustomChartLegend; + procedure FontChanged(Sender: TObject); function GetFont:TTeeFont; procedure S...

Hello,

I believe you only missed to set the ParentFont to False. This works for me (sorry for the colors chosen ):

Hello,

I've seen there's a problem in TeeRecompile/TeeInstall that makes the backup of the Lite version shipped with the IDE not to be done correctly for android 32 bits.
You should be able to workaround this by moving the library path to the top of the list:

Hello,

You can change the series order with the ExchangeSeries method:

Hello,

I get that same error in Android 32-bit, but I get it for both "Development" and "Application Store" Configurations.
On the other hand, it seems to work fine for me here in Android 64-bit, for both Configurations.

Could you please double check to confirm we are in the same situation?

Hello, I've added it to the public tracker: #2775 . And already fixed it. labelsalternate.png Here the diff if you want to apply it in your sources: --- a/TeEngine.pas +++ b/TeEngine.pas @@ -6963,11 +6963,11 @@ var var tmpLabelSize : Integer; tmpLabelW : Boolean; - OldPosLabel : Integer; tmp : Integ...
